UVA 2835
FEATURES
- High output UVA LED
- Max. current = 150mA
- Package Dimension = 2.8mmX3.5mmX1.65mm
- View angel >120°
- RoHS compliant
- ESD 4KV
- Custom Bin available upon special request
SPECIFICATIONS
| Part No. | Radiant Power ( mW) |
View angle | Wavelength Wd(nm) |
Drive Current | Vf (typ.~Max) |
|---|---|---|---|---|---|
| QLUV05MZSH-365nm | 250 | >120° | 360~370 | 150mA | 3.5~3.8 |
| QLUV05KZSH-400nm | 300 | >120° | 395~405 | 150mA | 3.3~3.6 |
| QLUV05HZSH-420nm | 365 | >120° | 415~425 | 150mA | 3.2~3.5 |
